Replacement rubber for Bridge Saws
Each piece is 2m x 1mĀ
an average saw table will require 4 pieces
Price does not include transport cost
Composition
Pre-consumer rubber granules (NOT deriving from the recycling of end-of-life tires) agglomerated with first choice polyurethane resins
Technical data
FormatĀ Ā Ā Ā Panels
DimensionsĀ 2.000mmĀ x 1.000mm (+/- 2%)
Possibility of cutting to size on customer request. Cutting precision (+/- 5 mm.)
ThicknessĀ Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā AVAILABLE IN 20mm OR 30 mm. (+/- 1.5 mm.)
DensityĀ Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā 850 kg./mc. (+/- 5%) granulometria 1-3 mm.
ColorĀ Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Black
Thermal conductivity Ī» = 0,11 W/(m.k)
Resistance temp.Ā Ā Ā Ā Ā Ā Ā -20Ā°C +110Ā°C
Reaction to fireĀ Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā B2
FeaturesĀ Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā Ā
It is sufficiently rigid to support the weight of the marble slabs even of thin thickness.
It is not hygroscopic and does not deform with the jets of water cooling the tools and cleaning of processing residues.
Does not damage the cutting discs.
Offers a support surface with excellent grip.
Does not conduct electricity.
Resistant to acids, sunlight, oils
Does not rot
Excellent resistance over time
The product does not contain dangerous and toxic substances and is not subject to the obligations established by Directive 67/648 / EEC.
Replacement O-ring for regular motor maintenance
