OMAG – Replacement Rubber for CNC Suction pads

Replacement rubber for Bridge Saws

Each piece is 2m x 1m

an average saw table will require 4 pieces Price does not include transport cost

Composition

Pre-consumer rubber granules (NOT deriving from the recycling of end-of-life tires) agglomerated with first choice polyurethane resins

Technical data

Format       Panels Dimensions  2.000mm  x 1.000mm (+/- 2%) Possibility of cutting to size on customer request. Cutting precision (+/- 5 mm.) Thickness                 AVAILABLE IN 20mm OR 30 mm. (+/- 1.5 mm.) Density                       850 kg./mc. (+/- 5%) granulometria 1-3 mm. Color                           Black Thermal conductivity λ = 0,11 W/(m.k) Resistance temp.        -20°C +110°C Reaction to fire            B2

Features

It is sufficiently rigid to support the weight of the marble slabs even of thin thickness. It is not hygroscopic and does not deform with the jets of water cooling the tools and cleaning of processing residues. Does not damage the cutting discs. Offers a support surface with excellent grip. Does not conduct electricity. Resistant to acids, sunlight, oils Does not rot Excellent resistance over time The product does not contain dangerous and toxic substances and is not subject to the obligations established by Directive 67/648 / EEC.
