C Model
“C” channel profile jib model
Capacity range 125 to 1000 kg
Jib length 3 to 7 m
This model is characterized by the extreme ease of handling due to the low inertia deriving from the light weight. The jib is normally fitted with a special “channel” profile trolley, which allows it to be easily push/pull.
H Model
“H” overbraced jib model
Capacity 250 to 2000 kg
Jib length 4 to 8 m
This model allows the use of the jib crane for greater capacities and slewing range than the C and T models. The jib allows the addition of electric and mechanical push-trolleys.
Technical Data
| Capacity (kg) | Jib length (M) | Total Column Height (m) |
|---|---|---|
| 125 | 3-7 | 3-5 |
| 250 | 3-7 | 3-5 |
| 500 | 3-7 | 3-5 |
| 1000 | 3-7 | 3-5 |
Technical Data
| Capacity (kg) | Jib length (M) | Total Column Height (m) |
|---|---|---|
| 250 | 4-8 | 3-5 |
| 500 | 4-8 | 3-5 |
| 1000 | 4-7 | 3-5 |
| 2000 | 4-5 | 3-5 |
S Model
“S” articulated jib model
Capacity 125 to 500 kg
Jib length 3 to 7 m
The jib of this model is articulated in two “hinged segments” which allow the handling even if fixed obstacles are present. This model permits the best use of the vertical room available and the clockwise/anticlockwise swing for more than 360°.
T Model
“T” cantilever jib model
Capacity 125 to 2000 kg
Jib length 2 to 5 m
This model allows the best use of the vertical room available thanks to the absence of rod and permits the maximum use of the hook path. The arm allows the addition of electric or mechanical push-trolleys.
Technical Data
| Capacity (kg) | Jib length (M) | Total Column Height (m) |
|---|---|---|
| 125 | 3-7 | 3-5 |
| 250 | 3-7 | 3-5 |
| 500 | 3-7 | 3-5 |
Technical Data
| Capacity (kg) | Jib length (M) | Total Column Height (m) |
|---|---|---|
| 125 | 2-5 | 3-5 |
| 250 | 2-5 | 3-5 |
| 500 | 2-5 | 3-5 |
| 1000 | 2-5 | 3-5 |
| 2000 | 2-5 | 3-5 |
